Self-Drilling Screw
Home / Products / Screw / Self-Drilling Screw / Countersunk Head Self-Drilling Screw
Self-Drilling Screw

Countersunk Head Self-Drilling Screw

Product Overview
The Countersunk Head Self-Drilling Screw features a conical, flush-mount head combined with an integrated drill point. This design creates smooth, low-profile connections in metal and wood without the need for pre-drilling or countersinking.

Send Inquiry
Zhejiang Chance & Union Import and Export Co., Ltd.
PREV：Hex Head Self-Drilling ScrewNEXT：Pan Head Self-Drilling Screw
Zhejiang Chance & Union Import and Export Co., Ltd.
Attributes
Zhejiang Chance & Union Import and Export Co., Ltd.

Key Features
Countersunk head sits flush with the material surface for a clean finish.
Integrated drill point eliminates the need for pre-drilled pilot holes.
Combines drilling, tapping, and countersinking in one installation step.
Creates flush, vibration-resistant joints in metal and wood.
Compatible with standard drive tools for efficient assembly.

Product Features
Zhejiang Chance & Union Import and Export Co., Ltd.
Grade Carbon Steel (5.8 / 8.8) / Stainless Steel 304 / 316 / Bi-metal
Size Range ST3.5–ST6.3 / #6–1/4" (custom sizes available)
Thread Type Self-drilling tapping thread (with drill point)
Standards DIN 7504 / ISO 15480 / ASME B18.6.3
Head Style  Pan head / countersunk head/hex head/wafer head optional
Drive Type Phillips / torx / hex drive optional
Drill Point Type Type 1 (light gauge) / Type 2 (medium gauge) / Type 3 (heavy gauge)
Material Carbon Steel / Stainless Steel 304 / 316 / Bi-metal (carbon steel drill point)
Surface Finish Zinc Plated / Zinc Flake / Black Oxide / Dacromet
Hardness HRB 150–220 (drill point hardened)
Operating Temperature  -40°C ~ 200°C (material-dependent)
Application Steel framing, roofing, metal decking, HVAC, automotive
Applications
Zhejiang Chance & Union Import and Export Co., Ltd.

Applications
Metal roofing installation, cabinetry assembly, architectural metalwork, and flat-panel construction.
